Ford Focus II (2005-2008) left front power window motor Wiring diagrams
This page contains all the electrical diagrams for the component. left front power window motor, in which he is found in the car Ford Focus II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front power window motor (1 of 2)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DN REST REST ONE- TOUCH DOWN ONE- TOUCH DOWN
DRIVER SWITCH
FUSE 55
GRN WIRE
GRN/WHT WIRE
HOT IN START OR RUN
ILLUMINATION
LEFT FRONT POWER WINDOW MOTOR
MASTER WINDOW ADJUST SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
PASSENGER SWITCH
REST UP
RIGHT FRONT POWER WINDOW MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, without rear power windows -> LEFT FRONT POWER WINDOW MOTOR
Wiring diagram left front power window motor (2 of 2)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DN REST REST ONE- TOUCH DOWN ONE- TOUCH DOWN
DRIVER SWITCH
FUSE 54
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN START OR RUN
ILLUMINATION
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LEFT REAR SWITCH
LEFT REAR WINDOW ADJUST SWITCH
LOCK
MASTER WINDOW ADJUST SWITCH
ONE-TOUCH WINDOW RELAY (IN DRIVER DOOR, BEHIND TRIM PANEL)
ORG/ WIRE
PASS SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
RED WIRE
REST UP
RIGHT REAR SWITCH
RIGHT REAR WINDOW ADJUST SWITCH
TO PASSENGER SIDE WINDOW ADJUST SWITCH (DIAGRAM 1 OF 1)
UP DN
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power windows circuit, with rear power windows -> LEFT FRONT POWER WINDOW MOTOR
