Car Wiring Diagrams for Passive anti-theft circuit for Ford Focus I facelift (2001-2007)

1 2 3 4 VPWR GND TX RX BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPT) BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 36 FUSE 61 GRN/BLK WIRE GRN/BLU WIRE GRN/YEL WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER ORG/ WIRE ORG/BLK WIRE PASSIVE ANTI-THEFT TRANSCEIVER MODULE PATS IND POWER HOLD RELAY FUSE 9 RED WIRE STARTING/ CHARGING SYSTEM WHT/GRN WIRE
