Ford Focus I facelift (2001-2007) vss vpwr vref vref gnd Wiring diagram
This page shows the only wiring diagram for the component.vss vpwr vref vref gnd, which is found in the car Ford Focus I facelift (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vss vpwr vref vref gnd (1 of 1)
1 2 3 4 5 6 7 8 9 10 VBATT
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DOWN/ OPEN
FUSE 34
FUSE 43
GRN/BLK WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
MOONROOF ADJUST SWITCH
ORG/BLK WIRE
ROOF OPENING PANEL UNIT (AT CENTER FRONT OF ROOF)
UP/ CLOSE
VSS
VSS VPWR VREF VREF GND
WHT/BLU WIRE
WHT/VIO WIRE
Go to component -> Power top/sunroof circuit -> VSS VPWR VREF VREF GND
