Ford Focus I facelift (2001-2007) low speed engine cooling fan relay b a/c compressor clutch diode Wiring diagram
This page shows the only wiring diagram for the component.low speed engine cooling fan relay b a/c compressor clutch diode, which is found in the car Ford Focus I facelift (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low speed engine cooling fan relay b a/c compressor clutch diode (1 of 1)
A/C CLUTCH FIELD COIL RIGHT FRONT PARK/TURN LAMP
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
COOLING FAN MOTOR DIODE 1
DAYTIME RUNNING LAMPS (DRL) RELAY
FOG LAMP RELAY
FUEL PUMP RELAY
GRN WIRE
HIGH BEAM RELAY
HORN
IGNITION RELAY
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN LAMP
LEFT HEADLAMP
LOW BEAM RELAY
LOW SPEED ENGINE COOLING FAN RELAY B A/C COMPRESSOR CLUTCH DIODE
MASS AIR FLOW (MAF SENSOR)
ORG/ WIRE
POWER HOLD RELAY
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SECOND COOLING FAN MOTOR
SPEED CONTROL SERVO
VEHICLE SPEED SENSOR (VSS)
WHT WIRE
WINDSHIELD WIPER MOTOR ENGINE COMPARTMENT SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> LOW SPEED ENGINE COOLING FAN RELAY B A/C COMPRESSOR CLUTCH DIODE
