Ford Focus I facelift (2001-2007) 2 14 vpwr vref Wiring diagram
This page shows the only wiring diagram for the component.2 14 vpwr vref, which is found in the car Ford Focus I facelift (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 14 vpwr vref (1 of 1)
2 14 VPWR VREF
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DECKLID RELAY
FUSE 34
FUSE 37
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN WIRE
HOT AT ALL TIMES
LIFTGATE/ DECKLID ANTI-THEFT INHIBIT SWITCH (IN DECKLID)
LUGGAGE COMPARTMENT LID RELEASE RELAY (LEFT SIDE OF LUGGAGE COMPT)
LUGGAGE COMPARTMENT LID RELEASE SOLENOID (IN DECKLID)
ORG/ WIRE
ORG/BLK WIRE
VREF
WHT WIRE
WHT/BLU WIRE
Go to component -> Trunk, tailgate, fuel door circuit, sedan -> 2 14 VPWR VREF
