Power window circuit, with rear power windows for Ford Focus I (1998-2004)
Power window circuit, with rear power windows
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DRIVER'S SIDE FRONT SWITCH
DRIVER'S WINDOW OPERATING SWITCH
FROM FUSE 56 (DIAGRAM 1 OF 1)
FUSE 54
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN RUN AND START
ILLUMINATION
IN RIGHT KICK PANEL)
LEFT FRONT WINDOW MOTOR
LEFT REAR SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
OFF OFF
OFF UP
ONE- TOUCH DOWN
ONE- TOUCH WINDOW RELAY (BEHIND TRIM PANEL)
ORG/ WIRE
REAR WINDOW CUTOFF SWITCH
RED WIRE
RIGHT FRONT SWITCH UP DOWN
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TO RIGHT FRONT WINDOW SWITCH (DIAGRAM 1 OF 1)
UP DOWN
VIO WIRE
WHT WIRE
YEL WIRE
