Ford Focus I (1998-2004) Instrument illumination circuit

AUXILIARY INSTRUMENT CLUSTER (3-DOOR) BLK WIRE BLU WIRE CENTRAL JUNCTION BOX DRIVER SIDE FRONT WINDOW OPERATING SWITCH DRIVER SIDE FRONT WINDOW OPERATING SWITCH REAR WINDOW CUTOFF SWITCH FRONT CIGAR LIGHTER GEARSHIFT LEVER UNIT FUSE 30 FUSE 54 FUSE 55 FUSE 59 GENERIC ELECTRONIC MODULE (GEM) (RIGHT "A" PILLAR) GRN WIRE GRN/WHT WIRE HEAD OFF PARK HEATER CONTROL MODULE HAZARD FLASHER SWITCH HEATER PANEL ILLUMINATON LAMP HOT AT ALL TIMES HOT IN RUN OR START ILLUMINATION INSTRUMENT CLUSTER LEFT FRONT SEAT HEATER SWITCH RIGHT FRONT SEAT HEATER SWITCH LIGHT SWITCH ORG/ WIRE ORG/BLU WIRE RADIO RED WIRE RIGHT FRONT WINDOW OPERATING SWITCH RIGHT REAR SIDE WINDOW OPERATING SWITCH LEFT REAR SIDE WINDOW OPERATING SWITCH TRACTION CONTROL SYSTEM DISABLE SWITCH W/ FRONT POWER WINDOWS W/O A/C W/ A/C W/O FRONT POWER WINDOWS WHT WIRE YEL WIRE
