Heated mirrors circuit for Ford Focus I (1998-2004)
Heated mirrors circuit
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENG COMPT)
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
CENTRAL JUNCTION BOX (BJB) (BEHIND LEFT SIDE OF DASH) FUSE 45
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DEFROST RELAY
DRIVER SIDE MIRROR MOTOR
FUSE 50
FUSE 7
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEATER CONTROL MODULE (IN DASH PANEL)
HEATER HEATER
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION SWITCH
LOCK
ORG/GRN WIRE
PASSENGER SIDE MIRROR MOTOR
REAR WINDOW
RED WIRE
RUN WIRE
