Cooling fan circuit, without a/c for Ford Focus I (1998-2004)
Cooling fan circuit, without a/c
38 68 91 SENSOR SIGNAL SWITCHED GROUND SENSOR RETURN
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT) FUSE 2
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU WIRE
BRN (OR WIRE
BRN WIRE
BRN/RED WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
COOLING FAN MOTOR DIODE
DIODE
ENGINE COOLING FAN MOTOR (IN LEFT FRONT OF ENGINE COMPARTMENT, BEHIND RADIATOR)
ENGINE COOLING FAN RELAY
FUSE 6
FUSE 9
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IGNITION SWITCH
NCA WIRE
OFF
ORG/ WIRE
POWER HOLD RELAY
RED WIRE
RUN WIRE
SPI+
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
ZETEC-E
