Anti-lock brake circuits, without traction control for Ford Focus I (1998-2004)
Anti-lock brake circuits, without traction control
ABS CONTROL MODULE (UNDER MASTER CYLINDER)
ABS IND.
BATTERY JUNCTION BOX (LEFT REAR CORNER OF ENGINE COMPT)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE 11
FUSE 21
FUSE 42
FUSE 46
GRN WIRE
GRN/ORG WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
INSTRUMENT CLUSTER
LEFT FRONT WHEEL SPEED SENSOR (ON WHEEL HUB)
LEFT REAR WHEEL SPEED SENSOR (ON WHEEL HUB)
NCA WIRE
ORG/ WIRE
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON WHEEL HUB)
RIGHT REAR WHEEL SPEED SENSOR (ON WHEEL HUB)
STOPLAMP SWITCH (ON UPPER RIGHT SIDE OF PEDAL BRACKET)
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
