Ford Focus I (1998-2004) w/ rear power windows w/o rear power windows 3 1 Wiring diagram
This page shows the only wiring diagram for the component.w/ rear power windows w/o rear power windows 3 1, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rear power windows w/o rear power windows 3 1 (1 of 1)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
CLOCK- SPRING
DATA LINK CONNECTOR
DRIVER DOOR LOCK MOTOR
DRIVER DOOR LOCK/UNLOCK SWITCH
DRIVER SIDE MIRROR MOTOR
DRIVER SIDE REAR DOOR AJAR SWITCH
DRIVER WINDOW OPERATING SWITCH
FRONT CIGAR LIGHTER
FRONT INTERIOR LAMP
GENERIC ELECTRONIC MODULE DEMISTING SWITCH
GRN WIRE
HEATER BLOWER SWITCH
HEATER CONTROL MODULE MULTIFUNCTION SWITCH
HEATER PANEL ILLUMINATION LAMP
INSTRUMENT CLUSTER
LEFT REAR WINDOW OPERATING SWITCH DRIVER SIDE FRONT DOOR AJAR SWITCH
LIFTGATE DECKLID SWITCH
LIGHT SWITCH
MOONROOF ADJUST SWITCH MOONROOF UNIT
NCA WIRE
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER MODULE HAZARD FLASHER SWITCH
POWER MIRROR ADJUST SWITCH
POWER POINT
REAR WINDOW WIPER MOTOR
REAR WIPER RELAY
RED WIRE
RIGHT LICENSE PLATE LAMP LEFT LICENSE PLATE LAMP
SEAT BELT BUCKLE SWITCH DRIVER SIDE FRONT SEAT ADJUST SWITCH
STEERING POSITION SENSOR
TAILGATE/ DECKLID ANTI-THEFT INHIBIT SWITCH HIGH MOUNT STOP LAMP
TAILGATE/ DECKLID RELEASE SWITCH
W/ AIR CONDITIONING
W/ REAR POWER WINDOWS W/O REAR POWER WINDOWS 3 1
WHT WIRE
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> W/ REAR POWER WINDOWS W/O REAR POWER WINDOWS 3 1
