Ford Focus I (1998-2004) right rear side window operating switch left rear side window operating switch Wiring diagram
This page shows the only wiring diagram for the component.right rear side window operating switch left rear side window operating switch, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear side window operating switch left rear side window operating switch (1 of 1)
AUXILIARY INSTRUMENT CLUSTER (3-DOOR)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
DRIVER SIDE FRONT WINDOW OPERATING SWITCH
DRIVER SIDE FRONT WINDOW OPERATING SWITCH REAR WINDOW CUTOFF SWITCH
FRONT CIGAR LIGHTER GEARSHIFT LEVER UNIT
FUSE 30
FUSE 54
FUSE 55
FUSE 59
GENERIC ELECTRONIC MODULE (GEM) (RIGHT "A" PILLAR)
GRN WIRE
GRN/WHT WIRE
HEAD OFF PARK
HEATER CONTROL MODULE HAZARD FLASHER SWITCH
HEATER PANEL ILLUMINATON LAMP
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUMINATION
INSTRUMENT CLUSTER
LEFT FRONT SEAT HEATER SWITCH RIGHT FRONT SEAT HEATER SWITCH
LIGHT SWITCH
ORG/ WIRE
ORG/BLU WIRE
RADIO
RED WIRE
RIGHT FRONT WINDOW OPERATING SWITCH
RIGHT REAR SIDE WINDOW OPERATING SWITCH LEFT REAR SIDE WINDOW OPERATING SWITCH
TRACTION CONTROL SYSTEM DISABLE SWITCH
W/ FRONT POWER WINDOWS
W/O A/C W/ A/C
W/O FRONT POWER WINDOWS
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> RIGHT REAR SIDE WINDOW OPERATING SWITCH LEFT REAR SIDE WINDOW OPERATING SWITCH
