Ford Focus I (1998-2004) right head- lamp hi lo Wiring diagrams
This page contains all the electrical diagrams for the component. right head- lamp hi lo, in which he is found in the car Ford Focus I (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right head- lamp hi lo (1 of 2)
BATTERY JUNCTION BOX
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CENTRAL JUNCTION BOX
DAYTIME RUNNING LAMPS RELAY
DAYTIME RUNNING LAMPS RESISTOR (IN LEFT REAR CORNER OF ENGINE COMPT)
FOG LAMP RELAY
FOG LAMPS
FUSE 16 FUSE 26
FUSE 17 FUSE 27
FUSE 22
FUSE 44 FUSE 59
GRN WIRE
HI-BEAM IND
HIGH BEAM RELAY
HIGH NEUTRAL FLASH
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEAD- LAMP LO HI
LIGHT SWITCH
LOW BEAM
LOW BEAM RELAY
MULTIFUNCTON SWITCH
NEUTRAL HIGH
OFF
OFF LOW BEAM PARK
ORG/ WIRE
PARK
RED WIRE
RIGHT FOG LAMP
RIGHT HEAD- LAMP HI LO
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, with drl -> RIGHT HEAD- LAMP HI LO
Wiring diagram right head- lamp hi lo (2 of 2)
BATTERY JUNCTION BOX
BLK WIRE
BLK/ORG WIRE
BLU WIRE
CENTRAL JUNCTION BOX
FOG LAMP RELAY
FOG LAMPS
FUSE 16 FUSE 26
FUSE 17
FUSE 27
FUSE 44
FUSE 61
GRN WIRE
HI-BEAM IND
HIGH BEAM RELAY
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEAD- LAMP LO HI
LIGHT SWITCH
LOW BEAM
LOW BEAM RELAY
MULTIFUNCTON SWITCH
NEUTRAL
NEUTRAL HIGH
OFF
ORG/ WIRE
PARK
RED WIRE
RIGHT FOG LAMP
RIGHT HEAD- LAMP HI LO
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> RIGHT HEAD- LAMP HI LO
