Ford Focus I (1998-2004) right front window motor Wiring diagrams
This page contains all the electrical diagrams for the component. right front window motor, in which he is found in the car Ford Focus I (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front window motor (1 of 2)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DRIVER'S POWER WINDOW SWITCH
DRIVER'S SIDE SWITCH
FUSE 55
GRN WIRE
GRN/WHT WIRE
HOT IN RUN AND START
IN RIGHT KICK PANEL)
LEFT FRONT WINDOW MOTOR
OFF OFF
OFF UP
ONE TOUCH
PASSENGER'S SIDE SWITCH
PASSENGERS WINDOW SWITCH
RIGHT FRONT WINDOW MOTOR
UP DOWN
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power window circuit, without rear power windows -> RIGHT FRONT WINDOW MOTOR
Wiring diagram right front window motor (2 of 2)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DRIVER'S SIDE FRONT SWITCH
DRIVER'S WINDOW OPERATING SWITCH
FROM FUSE 56 (DIAGRAM 1 OF 1)
FUSE 54
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN RUN AND START
ILLUMINATION
IN RIGHT KICK PANEL)
LEFT FRONT WINDOW MOTOR
LEFT REAR SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
OFF OFF
OFF UP
ONE- TOUCH DOWN
ONE- TOUCH WINDOW RELAY (BEHIND TRIM PANEL)
ORG/ WIRE
REAR WINDOW CUTOFF SWITCH
RED WIRE
RIGHT FRONT SWITCH UP DOWN
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TO RIGHT FRONT WINDOW SWITCH (DIAGRAM 1 OF 1)
UP DOWN
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power window circuit, with rear power windows -> RIGHT FRONT WINDOW MOTOR
