Ford Focus I (1998-2004) recirc on off Wiring diagram
This page shows the only wiring diagram for the component.recirc on off, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram recirc on off (1 of 1)
BATTERY JUNCTION BOX (BJB) (IN LEFT REAR CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DE-ICING SWITCH
DEFOGGER SYSTEM
FUSE 36
FUSE 45
FUSE 64
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HEATER BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH)
HEATER BLOWER SERIES RESISTOR (UNDER RIGHT SIDE OF DASH, NEXT TO BLOWER MOTOR)
HEATER BLOWER SWITCH
HEATER CONTROL MODULE
HOT AT ALL TIMES
HOT IN RUN OR START
MED LOW HIGH
NEUTRAL MAXIMUM SPEED
OFF
ON OFF ON
ORG/ WIRE
ORG/GRN WIRE
REAR WINDOW HEATER ON
REAR WINDOW HEATER SWITCH
REAR WINDOW HEATER SWITCH ILLUMINATION
RECIRC ON OFF
RECIRCULATION AIR ACTUATOR (BEHIND RIGHT SIDE OF DASH, NEXT TO BLOWER MOTOR)
RECIRCULATION ON
RECIRCULATION SWITCH
RECIRCULATION SWITCH ILLUMINATION
RED WIRE
SOLID STATE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Heater circuit -> RECIRC ON OFF
