Ford Focus I (1998-2004) rear window cutoff switch wiring diagram
This page shows the only wiring diagram for the component.rear window cutoff switch, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear window cutoff switch wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DRIVER'S SIDE FRONT SWITCH
DRIVER'S WINDOW OPERATING SWITCH
FROM FUSE 56 (DIAGRAM 1 OF 1)
FUSE 54
FUSE 55
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT IN RUN AND START
ILLUMINATION
IN RIGHT KICK PANEL)
LEFT FRONT WINDOW MOTOR
LEFT REAR SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
OFF OFF
OFF UP
ONE- TOUCH DOWN
ONE- TOUCH WINDOW RELAY (BEHIND TRIM PANEL)
ORG/ WIRE
REAR WINDOW CUTOFF SWITCH
RED WIRE
RIGHT FRONT SWITCH UP DOWN
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
RIGHT REAR SWITCH
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
TO RIGHT FRONT WINDOW SWITCH (DIAGRAM 1 OF 1)
UP DOWN
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power window circuit, with rear power windows -> REAR WINDOW CUTOFF SWITCH
