Ford Focus I (1998-2004) passenger side front window operating switch Wiring diagram
This page shows the only wiring diagram for the component.passenger side front window operating switch, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side front window operating switch (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CLOCK- SPRING
DRIVER SIDE FRONT WINDOW OPERATING SWITCH
DRIVER SIDE WINDOW OPERATING SWITCH
DRIVER'S WINDOW OPERATING SWITCH
FROM FUSE 1 (DIAGRAM 3 OF 4)
FUSE 42
FUSE 43
FUSE 52
FUSE 53
FUSE 54
FUSE 55
FUSE 56
GRN WIRE
GRN/YEL WIRE
LEFT FRONT SEAT HEATER SWITCH
MOONROOF ADJUST SWITCH
MOONROOF UNIT
ONE-TOUCH WINDOW RELAY
ORG/ WIRE
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER SIDE FRONT WINDOW OPERATING SWITCH
REAR WINDOW WIPER MOTOR
REAR WIPER RELAY
RED WIRE
RIGHT FRONT SEAT HEATER SWITCH
SPEED CONTROL MODULE
STOPLAMP SWITCH
W/ REAR POWER WINDOWS
W/ SPEED CONTROL
W/O REAR POWER WINDOWS
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> PASSENGER SIDE FRONT WINDOW OPERATING SWITCH
