Ford Focus I (1998-2004) instrument cluster left turn ind. right turn ind. Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster left turn ind. right turn ind., which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster left turn ind. right turn ind. (1 of 1)
3 DOOR, WAGON
4 DOOR
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
FUSE 30
FUSE 32
FUSE 57
FUSE 58
FUSE 62
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN WIRE
HAZARD FLASHER SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER LEFT TURN IND. RIGHT TURN IND.
LEFT LICENSE PLATE LAMP
LEFT REAR LAMP ASSEMBLY
LEFT REAR TURN LAMP
LEFT SIDE FRONT PARK/ TURN LAMP
LEFT SIDE TURN SIGNAL LAMP
LIGHT SWITCH (LEFT SIDE OF DASH)
MULTIFUNCTION SWITCH
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
RED WIRE
RIGHT LICENSE PLATE LAMP
RIGHT REAR LAMP ASSEMBLY
RIGHT REAR TURN LAMP
RIGHT SIDE FRONT PARK/ TURN LAMP
RIGHT SIDE TURN SIGNAL LAMP
RT LT
TURN SIGNAL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> INSTRUMENT CLUSTER LEFT TURN IND. RIGHT TURN IND.
