Ford Focus I (1998-2004) high beam relay low beam relay Wiring diagram
This page shows the only wiring diagram for the component.high beam relay low beam relay, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high beam relay low beam relay (1 of 1)
-1 +2
1/+
A/C WIDE OPEN THROTTLE (WOT) RELAY
BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DIODE
ELECTRIC VACUUM REGULATOR (EVR) SOLENOID VALVE
ENGINE
ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ENGINE COOLING FAN RELAY
EVAP CANISTER PURGE VALVE
EVAPORATIVE EMISSION (EVAP) CANISTER VENT VALVE
EXCEPT SVT SVT (1) (2)
FROM BATTERY (DIAGRAM 1 OF 4)
FROM FUSE 9 (DIAGRAM 1 OF 4)
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FUEL PUMP RELAY
FUSE 1 FUSE 64
FUSE 15
FUSE 18
FUSE 28
FUSE 40
GEARSHIFT LEVER UNIT
GRN WIRE
GRN/BLU WIRE
HEATED OXYGEN SENSOR 11
HEATED OXYGEN SENSOR 12
HEATER BLOWER MOTOR
HIGH BEAM RELAY LOW BEAM RELAY
HIGH SPEED ENGINE COOLING FAN RELAY
IDLE SPEED CONTROL VALVE INLET MANIFOLD RUNNER CONTROL (IMRC) MODULE
IGNITION COIL
IGNITION RELAY
INJECTOR 1 CAMSHAFT TIMING ACTUATOR
INJECTOR 2
INJECTOR 3
INJECTOR 4
LEFT REVERSING LAMP RIGHT REVERSING LAMP
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
ORG/ WIRE
POWER HOLD RELAY
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RELAY
RUN WIRE
TO FUSE 53 (DIAGRAM 4 OF 4)
TRANSMISSION RANGE SENSOR
VEHICLE SPEED SENSOR
W/O DRL
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> HIGH BEAM RELAY LOW BEAM RELAY
