Ford Focus I (1998-2004) ground ground ign coil start sig vss out o/d sw Wiring diagram

1 (OR 2) 1 POS 2 POS 2 (OR 1) A/C WIDE OPEN THROTTLE RELAY ANTI-THEFT SYSTEM (PATS IND) BATTERY JUNCTION BOX (BJB) (LEFT REAR CORNER OF ENGINE COMPT) BLK WIRE BLK/BLU (OR BLK) WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COOLING FANS (HIGH SPEED FAN RELAY) CRUISE CONTROL SYSTEM, SOUND SYSTEMS D POS DATALINE DATALINE HIGH FAN DIODE DLC ELECTRONIC VACUUM REGULATOR SOLENOID VALVE (ON LEFT SIDE OF FIREWALL) ENGINE COOLING FAN RELAY FUEL PUMP FUEL PUMP DRIVER MODULE (UNDER RIGHT REAR SEAT) FUEL PUMP RELAY FUEL TANK UNIT FUSE 12 FUSE 18 FUSE 8 FUSE 9 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GROUND IGN COIL START SIG VSS OUT O/D SW GROUND IGN COIL PATS FP DRIVER GRY/ORG WIRE HIGH SPEED ENGINE COOLING FAN RELAY HOT AT ALL TIMES IGNITION COIL (ON REAR OF CYLINDER HEAD) IGNITION RELAY IGNITION SWITCH IGNITION TRANSFORMER CAPACITOR (ON REAR OF CYL HEAD, BESIDE IGN COIL) IMRC R POS (SPI) INERTIA FUEL SHUTOFF SWITCH (BEHIND RIGHT KICK PANEL) LOCK MAF TFT SENS ECT CHT ACT FP DRIVER AC PRESS PATS IND MIL IND ECR SOL ORG/ WIRE ORG/BLK WIRE OSS TSS PATS INJ 3 CKP SENS CKP SENS POWER HOLD RELAY PSP SW RED WIRE RUN WIRE SPI+ STARTER RELAY STARTING/CHARGING SYSTEM TO SPARK PLUGS TRANS UNIT WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE
