Ford Focus I (1998-2004) dual axis acceleration sensor Wiring diagram

ABS IND. BATTERY JUNCTION BOX BATTERY JUNCTION BOX (LEFT REAR CORNER OF ENGINE COMPT) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DUAL AXIS ACCELERATION SENSOR ELECTRONIC STABILITY PROGRAM MODULE (ON LEFT SIDE OF ENGINE COMPT) FUSE 11 FUSE 21 FUSE 36 FUSE 41 FUSE 42 FUSE 46 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ACC OR RUN INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR (ON WHEEL HUB) LEFT REAR WHEEL SPEED SENSOR (ON WHEEL HUB) NCA WIRE ORG/ WIRE ORG/WHT WIRE PRIMARY BRAKE PRESSURE SENSOR RED WIRE RIGHT FRONT WHEEL SPEED SENSOR (ON WHEEL HUB) RIGHT REAR WHEEL SPEED SENSOR (ON WHEEL HUB) SECONDARY BRAKE PRESSURE SENSOR STEERING POSITION SENSOR (ON STEERING COLUMN) STOPLAMP RELAY STOPLAMP SWITCH (ON UPPER RIGHT SIDE OF PEDAL BRACKET) TRACTION CONTROL IND TRACTION CONTROL SWITCH VACUUM BRAKE BOOSTER WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YAW VELOCITY SENSOR YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE
