Ford Focus I (1998-2004) driver side mirror motor left/ right up/ down Wiring diagram
This page shows the only wiring diagram for the component.driver side mirror motor left/ right up/ down, which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side mirror motor left/ right up/ down (1 of 1)
BATTERY SAVER RELAY
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DEFOGGER SYSTEM
DRIVER SIDE MIRROR MOTOR LEFT/ RIGHT UP/ DOWN
FUSE 35
FUSE 36
FUSE 63
GENERIC ELECTRONIC MODULE (GEM) (ON RIGHT "A" PILLAR)
GRN WIRE
HOT AT ALL TIMES
INTERIOR LIGHTING
LEFT RIGHT LEFT RIGHT
LH MIRROR RH MIRROR
NOT USED
ORG/ WIRE
ORG/BLU WIRE
ORG/YEL WIRE
PASSENGER SIDE MIRROR MOTOR LEFT/ RIGHT UP/ DOWN
POWER MIRROR ADJUST SWITCH
RED WIRE
RH MIRROR LH MIRROR
UP DOWN
VIO WIRE
WHT WIRE
YEL WIRE
