Ford Focus I (1998-2004) abs control control module (under master cylinder) wiring diagram
This page shows the only wiring diagram for the component.abs control control module (under master cylinder), which is found in the car Ford Focus I (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
abs control control module (under master cylinder) wiring diagram (1 of 1)
ABS CONTROL CONTROL MODULE (UNDER MASTER CYLINDER)
AIR BAG DIAGNOSTIC MONITOR (UNDER CENTER CONSOLE)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, ON CENTRAL JUNCTION BOX)
ELECTRONIC STABILITY PROGRAM (ESP) MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE 10
GENERIC ELECTRONIC MODULE (RIGHT "A" PILLAR)
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
ORG/ WIRE
ORG/BLK WIRE
POWERTRAIN CONTROL MODULE (BASE OF "A" PILLAR)
RED WIRE
W/ DURATEC- ST
W/ ELECTRONIC STABILITY PROGRAM (ESP)
W/O ESP
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Computer data lines, without traction control -> ABS CONTROL CONTROL MODULE (UNDER MASTER CYLINDER)
