Courtesy lamps circuit, rs for Ford Focus RS III (2016-2018)

BLK/GRY WIRE BLK/WHT WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE CENTER INTERIOR LAMPS COMPUTER DATA LINES SYSTEM COURTESY DIMMING LIN DIMMING RTN DRV DOOR AJAR FRONT INTERIOR/MAP LAMPS ASSEMBLY FUSE 60 GLOVE COMPARTMENT LAMP GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/VIO WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) HOT AT ALL TIMES HS CAN+ INSTRUMENT ILLUMINATION CIRCUIT INTERIOR LIGHT RELAY LEFT VANITY MIRROR LAMP LIFTGATE AJAR LOGIC CONTROL LOGIC GND LR DOOR AJAR MAP MEGA FUSE 4 MEGA FUSE 9 MICRO - OVERHEAD CONSOLE SWITCH ASSEMBLY PASS DOOR AJAR PWR GND REAR DOME LAMP RED WIRE RIGHT VANITY MIRROR LAMP RR DOOR AJAR VBATT VIO/GRN WIRE VIO/GRY WIRE W/ ROOF OPENING PANEL W/O ROOF OPENING PANEL WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/VIO WIRE

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU/BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/VIO WIRE LEFT FRONT DOOR LATCH LEFT REAR DOOR LATCH LEFT REAR DOOR MODULE MS CAN + PASSENGER DOOR MODULE (PDM) POWER WINDOWS SYSTEM RIGHT FRONT DOOR LATCH RIGHT REAR DOOR LATCH RIGHT REAR DOOR MODULE RTN VIO/GRN WIRE WHT WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/WHT WIRE CUP HOLDER LAMP (W/ AMBIENT LIGHTING) DRIVER DOOR RELEASE LAMP GRN/BRN WIRE LEFT "C" PILLAR) LEFT FRONT FOOTWELL LAMP LEFT FRONT MAP POCKET LAMP LEFT LUGGAGE COMPARTMENT LAMP LIFTGATE/DECKLID LATCH ASSEMBLY MASTER WINDOW CONTROL SWITCH PASSENGER DOOR RELEASE LAMP RIGHT FRONT FOOTWELL LAMP RIGHT FRONT MAP POCKET LAMP RIGHT LUGGAGE COMPARTMENT LAMP VIO/GRN WIRE VPWR W/ AMBIENT LIGHTING W/O AMBIENT LIGHTING WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE
