Ford Focus RS III (2016-2018) Cooling fan circuit, rs
Cooling fan circuit, rs (1 of 2)
BATTERY JUNCTION BOX (BJB)
BRN WIRE
ECT
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
ENGINE COOLING FAN RELAY #1
ENGINE COOLING FAN RELAY #3
FUSE 34
FUSE 46
GRN/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HFC
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
LFC
MEGA FUSE 7
MEGA FUSE 8
POWERTRAIN CONTROL MODULE (PCM) (LEFT SIDE OF TRANSMISSION)
SIGRTN
VAFC
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Cooling fan circuit, rs (2 of 2)
BATTERY JUNCTION BOX (BJB)
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
ENGINE COOLING FAN RELAY #2
ENGINE COOLING FAN RELAY 4
ENGINE COOLING FAN RELAY 5
ENGINE COOLING FAN RESISTOR 1
ENGINE COOLING FAN RESISTOR 2
GRN/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
YEL/ORG WIRE
