Ford Focus RS III (2016-2018) pass frt cr sens rtn wiring diagram
This page shows the only wiring diagram for the component.pass frt cr sens rtn, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
pass frt cr sens rtn wiring diagram (1 of 1)
AMBER IND
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
CASE GND
COLLAPSIBLE STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
DEPLOY STEERING COLUMN FEED
DEPLOY STEERING COLUMN RTN
DRIVER LOWER AIR BAG MODULE
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRT CR SENS FEED
DRV FRT CR SENS RTN
DRV KNEE AIR FEED
DRV KNEE AIR RTN
ENS
FUSE 86
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
LEFT FRONT IMPACT SEVERITY SENSOR
MICRO -
NCA WIRE
PAD IND
PAD IND OFF
PAD IND ON
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS FRT CR SENS FEED
PASS FRT CR SENS RTN
PASSENGER AIR BAG CANISTER VENT
PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT IMPACT SEVERITY SENSOR
RUN/START
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit, except rs (1 of 3) -> PASS FRT CR SENS RTN
