Ford Focus RS III (2016-2018) lin video- Wiring diagram
This page shows the only wiring diagram for the component.lin video-, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin video- (1 of 1)
ACCESSORY PROTOCOL INTERFACE MODULE (APIM)
BATTERY JUNCTION BOX (RJB)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN BLK/ WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT RS
EXCEPT RS RS W/ START/STOP W/O START/STOP
FRONT CONTROL/DISPLAY INTERFACE MODULE (FCDIM)
FUSE 28
FUSE 29
GRN WIRE
GRY/ORG WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
IGN IN
IGN OUT
LIN 2
LIN VIDEO-
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MICRO -
MS CAN +
NCA WIRE
POWER DISTRIBUTION SYSTEM
R/S
REAR JUNCTION BOX (RJB)
RED WIRE
RED YEL/ WIRE
SHIELD
VIDEO CAMERA
VIDEO+
VIO) BLU/RED WIRE
VIO/ORG WIRE
VPWR
W/ SYNC GEN 1
W/ SYNC GEN 2, 3
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear camera circuit, except electric -> LIN VIDEO-
