Ford Focus RS III (2016-2018) limp home sw Wiring diagrams
This page contains all the electrical diagrams for the component. limp home sw, in which he is found in the car Ford Focus RS III (2016-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram limp home sw (1 of 2)
AUTOLAMP/ SUNLOAD SENSOR
AUTOLAMPS
BATTERY JUNCTION BOX (BJB)
BATTERY MONITORING SENSOR
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
COM
COMPUTER DATA LINES SYSTEM
FRONT WASHER RELAY
FRONT WIPER
FUSE 18
FUSE 42
FUSE 72
FUSE 77
FUSE 82
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT WINDSHIELD WIPER MOTOR
LEVEL SWITCH
LIMP HOME SW
LIN 1
LIN 8
MICRO -
MS CAN +
PWR GND
REAR JUNCTION BOX (RJB)
REAR WASHER RELAY
REAR WINDOW WIPER MOTOR
REAR WIPER
REAR WIPER RELAY
RIGHT FRONT WINDSHIELD WIPER MOTOR
RLY CTRL
SASM SPLY
SENS
SIG RTN
STEERING ANGLE SENSOR MODULE (SASM)
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
WASHER FLUID
WASHER FLUID LEVEL SWITCH
WASHER FLUID RESERVOIR)
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDSHIELD WASHER PUMP MOTOR
WIPER LIMP HOME
WIPER/WASHER SWITCH
Go to component -> Wiper/washer circuit, electric -> LIMP HOME SW
Wiring diagram limp home sw (2 of 2)
AUTOLAMPS
BATTERY JUNCTION BOX (BJB)
BATTERY MONITORING SENSOR
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM) (RIGHT SIDE OF DASH)
BRN/RED WIRE
COM
COMPUTER DATA LINES SYSTEM
FRONT WASHER RELAY
FRONT WIPER
FUSE 18
FUSE 33
FUSE 72
FUSE 77
FUSE 82
FUSE 85
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
LEFT "C" PILLAR)
LEFT FRONT WINDSHIELD WIPER MOTOR
LEVEL SWITCH
LIMP HOME SW
LIN 1
LIN 8
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MICRO -
MS CAN +
PWR GND
REAR JUNCTION BOX (RJB)
REAR WASHER RELAY
REAR WINDOW WIPER MOTOR
REAR WIPER
REAR WIPER RELAY
RIGHT FRONT WINDSHIELD WIPER MOTOR
RLY CTRL
SASM SPLY
SENS
SIG RTN
STEERING ANGLE SENSOR MODULE (SASM)
STEERING COLUMN ASSEMBLY
SUNLOAD SENSOR
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WASHER FLUID
WASHER FLUID LEVEL SWITCH
WASHER FLUID RESERVOIR)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WINDSHIELD WASHER PUMP MOTOR
WIPER LIMP HOME
WIPER/WASHER SWITCH
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiper/washer circuit, rs -> LIMP HOME SW
