Ford Focus RS III (2016-2018) cpp sigrtn Wiring diagram
This page shows the only wiring diagram for the component.cpp sigrtn, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cpp sigrtn (1 of 1)
ACCELERATOR PEDAL POSITION (APP) SENSOR
ACCR
AIR CONDITIONING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
CACT
CANV
CLUTCH PEDAL SWITCH
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CPP
CPP SIGRTN
CRANK DETECT
CRUISE CONTROL SYSTEM
EVAPCP
EVENT
FCV
FPC
FPM
FPPWR
FPRTN
FUEL
FUEL PMP
FUEL PUMP (FP) ASSEMBLY
FUEL PUMP CONTROL MODULE
FUEL PUMP RELAY
FUEL TANK
FUEL TANK PRESSURE (FTP) SENSOR
FUSE 56
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
IAT
INS
INSTRUMENT PANEL CLUSTER (IPC)
ISP-R
LVL GND
LVL SENS
MICRO -
MS CAN +
NCA WIRE
PCM WAKE
POWERTRAIN CONTROL MODULE (PCM)
REV GEAR SW
SIGNAL
SIGRTN
SMC
SME
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
STOP LIGHT
SWITCH
UP SUPPLY
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VPWR
VREF
VREF BBP
WAKE-UP
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (1 of 6) -> CPP SIGRTN
