Ford Focus RS III (2016-2018) cpp p/n sw/clutch 2 wake up Wiring diagram
This page shows the only wiring diagram for the component.cpp p/n sw/clutch 2 wake up, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cpp p/n sw/clutch 2 wake up (1 of 1)
AAT
ACCELERATION PEDAL POSITION (APP) SENSOR
ACCR
ACPT
AIR CONDITIONING SYSTEM STARTING/CHARGING SYSTEM
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BPP
BPS
BRN WIRE
BRN/WHT WIRE
CLUTCH PDL SW CANV
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CPP P/N SW/CLUTCH 2 WAKE UP
CRANK DETECT
CRASH
CRUISE CONTROL SYSTEM
FCV
FPM
FUSE 38
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
ISP-R
M/T A/T
MS CAN +
NCA WIRE
PCMRC
PEM PWM
POWERTRAIN CONTROL MODULE (PCM)
PWR GND
REVERSED GEAR SW
SIGRTN
SMC
SMCS
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TRANSMISSION ASSEMBLY
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0l (1 of 6) -> CPP P/N SW/CLUTCH 2 WAKE UP
