Ford Focus RS III (2016-2018) barometric absolute pressure sensor wiring diagram
This page shows the only wiring diagram for the component.barometric absolute pressure sensor, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
barometric absolute pressure sensor wiring diagram (1 of 1)
AAT
ACLP
BAP
BAROMETRIC ABSOLUTE PRESSURE SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CABIN HEATER COOLANT DIVERTER VALVE
CABIN HEATER COOLANT PUMP
CABIN HTR PWM
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
ELECTRIC MOTOR COOLANT DIVERTER VALVE
ELECTRIC MOTOR COOLANT PUMP
EV HS CAN -
FCV
GRN WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HIGH VOLTAGE BATTERY COOLANT COOLER THV, ISOLATOR SOLENOID VALVE ASSEMBLY
HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE
HIGH VOLTAGE BATTERY COOLANT PUMP
HVIL SENSE
HVIL SOURCE
ORG/BLU WIRE
ORG/GRY WIRE
PCM SHUTOFF IN
POWERTRAIN CONTROL MODULE (PCM)
SIGRTN
TEMPERATURE SENSOR THERMOSTAT 1
TEMPERATURE SENSOR THERMOSTAT 2
TEMPERATURE SENSOR THERMOSTAT 3
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance electric (8 of 8) -> BAROMETRIC ABSOLUTE PRESSURE SENSOR
