Ford Focus RS III (2016-2018) adaptive steering column - Wiring diagram
This page shows the only wiring diagram for the component.adaptive steering column -, which is found in the car Ford Focus RS III (2016-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adaptive steering column - (1 of 1)
ADAPTIVE STEERING COLUMN -
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/VIO WIRE
CASE GROUNDED
CENTER FRONT IMPACT SENSOR
COLLAPSIBLE STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
DRIVER KNEE AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV FRT CR SENS FEED
DRV FRT CR SENS RTN
DRV KNEE AIR BAG
ENS
FRONT CORNER OF ENGINE COMPT)
FUSE 86
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT W/ IGNITION RELAY ENERGIZED
HS CAN+
LEFT FRONT IMPACT SEVERITY SENSOR
MICRO -
NCA WIRE
PAD IND
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG ADAPTIVE VENTING -
PASS FRONT AIR BAG STAGE 2 -
PASS FRONT CRASH SENSOR +
PASSENGER AIR BAG CANISTER VENT
PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR
RESTRAINTS CONTROL MODULE (RCM) (UNDER FRONT OF CENTER CONSOLE)
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit, rs (1 of 3) -> ADAPTIVE STEERING COLUMN -
