Ford Focus RS III (2016-2018) acps sig Wiring diagrams
This page contains all the electrical diagrams for the component. acps sig, in which he is found in the car Ford Focus RS III (2016-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
acps sig wiring diagram (1 of 3)
2.0L
2.0L 2.0L TURBO
2.0L TURBO
2.0L, 2.0L TURBO 1.0L TURBO 2.0L
A/C RELAY
AAT GND
AAT SIG
ACPS SIG
ACPT
ACPT SIG
AGS LIN
AIR CONDITIONING (A/C) CLUTCH, AIR CONDITIONING (A/C) CLUTCH FIELD COIL
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER
BLOWER MOTOR
BLOWER MOTOR SPEED CONTROL
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL
ECT
ELECTRIC BOOSTER HEATER
ELECTRONICS ENGINE COOLING FAN MODULE
ENGINE CONTROLS SYSTEM
EXTERNALLY CONTROLLED VARIABLE DISPLACEMENT COMPRESSOR (EVDC)
FAN
FAN PWM
FCV
GRILLE SHUTTER ACTUATOR
GRN/BLU WIRE
GRN/BRN WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HS CAN+
IGN PLUS
LOWER RIGHT FRONT OF ENGINE)
MEGA FUSE 5
MEGA FUSE 8
MOTOR
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWM SIG
PWR
S120 (2.0L) S129 (2.0L TURBO)
S128 (2.0L TURBO) S161 (1.0L TURBO)
S133 (2.0L TURBO)
S159 (1.0L TURBO)
SIG RTN
SIGRTN
STARTING/ CHARGING SYSTEM
TRANSMISSION ASSEMBLY
VACC
VARIABLE
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPOWER
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, except electric & rs (2 of 3) -> ACPS SIG
acps sig wiring diagram (2 of 3)
2.0L
2.0L 2.0L TURBO
2.0L TURBO
2.0L, 2.0L TURBO 1.0L TURBO 2.0L
A/C RELAY
AAT GND
AAT SIG
ACCR
ACPS SIG
ACPT SIG
AGS LIN
AIR CONDITIONING (A/C) CLUTCH, AIR CONDITIONING (A/C) CLUTCH FIELD COIL
BLK WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
ECT
ELECTRIC BOOSTER HEATER
ELECTRONICS
ENGINE CONTROLS SYSTEM
ENGINE COOLING FAN MODULE (UPPER LEFT REAR OF FAN SHROUD ASSEMBLY)
EXTERNALLY CONTROLLED VARIABLE DISPLACEMENT COMPRESSOR (EVDC)
FAN CONTROL VARIABLE
FAN PWM
FCV
GRILLE SHUTTER ACTUATOR
GRN/BLU WIRE
GRN/BRN WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HS CAN+
IGN PLUS
LOWER RIGHT FRONT OF ENGINE)
MEGA FUSE 5
MEGA FUSE 8
NCA WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWM SIG
PWR
S120 (2.0L) S129 (2.0L TURBO)
S128 (2.0L TURBO) S161 (1.0L TURBO)
S133 (2.0L TURBO)
S159 (1.0L TURBO)
SIG RTN
SIGRTN
STARTING/ CHARGING SYSTEM
TRANSMISSION ASSEMBLY
VACC
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPOWER
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Manual a/c circuit (2 of 3) -> ACPS SIG
acps sig wiring diagram (3 of 3)
