3.5l, a/t circuit for Ford Flex I (2008-2013)

1 2 3 4 5 6 7 8 9 SSE TFT TFT SIG RTN TR-1 TR-2 TR-3 TR-4 TR GND TSS/OSS GND 10 11 12 13 14 15 16 17 18 19 20 OSS 2 3 55 7 8 51 52 53 16 46 HS CAN+ HS CAN- FEPS IGNITION PCM RLY CTRL 28 39 29 47 27 40 35 15 41 SSD SSA TCC TSPC SSB SSC LPC TSS TSS/OSS VPWR 34 51 59 60 61 66 41 58 TACM+ TACM- ETCRTN 38 20 43 17 18 19 32 45 SSE TFT TFT SIG RTN TR 1 TR 2 TR 3 TR 4 TSS/OSS/TR GND 47 21 25 26 27 28 59 65 66 67 68 69 70 BPS BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CASE GND PWR GND 1 PWR GND 2 PWR GND 3 PWR GND 4 COMPUTER DATA LINES SYSTEM CONTROL MODULE ENGINE CONTROLS SYSTEM ETC REF CHT E-SIGRTN FUSE 11 FUSE 37 FUSE 46 FUSE 14 FUSE 47 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN START OR RUN OSS + PCM POWER RELAY POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT) SSD SSA TCC TSPC SSB SSC LPC TSS TSS/OSS VPWR TCS BOO VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

1-NORMAL OPEN 2-OVERDRIVE ENABLE/ DISABLE ACCELERATOR PEDAL POSITION (APP) SENSOR (LEFT SIDE OF DASH) BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE PEDAL POSITION (BPP) SWITCH (LEFT SIDE OF DASH) BRN WIRE BRN/GRN WIRE BRN/RED WIRE CYLINDER HEAD TEMPERATURE SENSOR (TOP FRONT OF RIGHT CYLINDER HEAD) ELECTRONIC THROTTLE CONTROL (ETC) (TOP RIGHT REAR OF ENGINE) ENGINE CONTROLS SYSTEM FLOOR SHIFTER (CENTER CONSOLE) FUSE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE HOT IN START OR RUN SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) TRANSMISSION CONTROL SWITCH VIO/GRN WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WIRING HARNESS, NEAR BREAKOUT TO WINDSHIELD WIPER MOTOR) YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
