Power mirrors circuit for Ford Flex I (2008-2013)
Power mirrors circuit
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DEFOGGER DEFOGGER SYSTEM SYSTEM INTERIOR LIGHTS INTERIOR SYSTEM LIGHTS SYSTEM
DOWN
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 13
GRN/VIO WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT EXTERIOR REAR VIEW MIRROR (MIRROR ASSEMBLY)
LEFT RIGHT
LEFT/ RIGHT UP/ DOWN
MIRROR SELECT
RIGHT DOWN LEFT
RIGHT EXTERIOR REAR VIEW MIRROR (MIRROR ASSEMBLY)
RIGHT LEFT
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
UP DOWN
VIO WIRE
YEL/VIO WIRE
