Parking assistant circuit for Ford Flex I (2008-2013)

ACTIVE PARK ASSIST SWITCH (IF EQUIPPED) AUTO PARK SW BLK/BLU WIRE BLK/VIO WIRE BLU/GRN WIRE BLU/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT LEFT SIDE SN FRONT RIGHT SIDE SN FUSE 35 GRN/BLU WIRE GRN/BRN WIRE GRN/WHT WIRE GRY/ORG WIRE HOT IN START OR RUN HS CAN+ INNER LEFT PARKING AID SENSOR INNER RIGHT PARKING AID SENSOR LEFT REAR INNER SN LEFT REAR OUTER SN NCA WIRE OUTER LEFT PARKING AID SENSOR OUTER RIGHT PARKING AID SENSOR PARKING AID MODULE (PAM) (RIGHT "C" PILLAR) PARKING AID SPEAKER PWR RUN REAR SENS GND REAR SENS PWR REAR SOUNDER - RIGHT ACTIVE PARK ASSIST SENSOR RIGHT REAR INNER SN RIGHT REAR OUTER SN SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SOLID STATE STATUS LED VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE
