Ford Flex I (2008-2013) w/o power liftgate, amplifier Wiring diagrams
This page contains all the electrical diagrams for the component. w/o power liftgate, amplifier, in which he is found in the car Ford Flex I (2008-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o power liftgate, amplifier (1 of 2)
14 26 HS CAN- HS CAN+
26 25 13 12 HS CAN- HS CAN+ MS CAN- MS CAN+
55 3 2 63 58 59 FEPS HS CAN- HS CAN+
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT REAR OF ENGINE COMPT)
AUDIO CONTROL MODULE (ACM)
BLK/BLU WIRE
BRN WIRE
CONTROL MODULE (RIGHT
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) 3 2 HS CAN- HS CAN+
EXCEPT TURBO TURBO
FRONT CONTROL INTERFACE MODULE (FCIM) (CENTER OF DASH)
FRONT DISPLAY INTERFACE MODULE (FDIM) (W/ SYNC, W/O NAVIGATION)
FUSE 20
GRN/RED WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN+
INSTRUMENT CLUSTER (IC)
J/C 1 (LEFT REAR OF ENGINE COMPT)
J/C 10 (UNDER PASSENGER SEAT)
J/C 11 (LEFT FRONT OF ENGINE COMPT)
J/C 12 (LEFT FRONT OF ENGINE COMPT)
J/C 2 (LEFT SIDE OF DASH)
J/C 3 (LEFT SIDE OF DASH)
J/C 5 (RIGHT KICK PANEL)
KICK PANEL)
MS CAN +
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) (UNDER FRONT PASSENGER'S SEAT)
OF ENGINE)
POWER STEERING CONTROL MODULE (PSCM) (RIGHT REAR
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT)
RESTRAINTS CONTROL MODULE (RCM) (CENTER CONSOLE)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
STEERING ANGLE SENSOR MODULE (SASM) (W/ PARK ASSIST) (TOP OF STEERING COLUMN)
VIO/ORG WIRE
W/ AMPLIFIER
W/ POWER LIFTGATE
W/O POWER LIFTGATE, AMPLIFIER
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (1 of 2) -> W/O POWER LIFTGATE, AMPLIFIER
Wiring diagram w/o power liftgate, amplifier (2 of 2)
11 1 MS CAN- MS CAN+
11 10 MS CAN+ MS CAN-
14 15 MS CAN+ MS CAN-
3 2 MS CAN - MS CAN +
ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (CENTER CONSOLE)
AUDIO AMPLIFIER
DRIVER SEAT MODULE (DSM) (UNDER
DRIVER'S SEAT
GLOBAL POSITIONING SYSTEM
GRY/ORG WIRE
HS CAN+
HVAC MODULE (CENTER OF DASH)
J/C 4 (RIGHT SIDE OF DASH)
J/C 6 (W/ POWER LIFTGATE) (BASE OF LEFT "B" PILLAR)
J/C 7 (LEFT SIDE OF ROOF)
J/C 8 (W/ POWER LIFTGATE) (LEFT "D" PILLAR)
J/C 9 (W/ AMPLIFIER) (RIGHT REAR QUARTERPANEL)
LIFTGATE/TRUNK MODULE (LTM) (LEFT "D" PILLAR)
MODULE (GPSM) (W/ SYNC, W/O NAVIGATION)
MS CAN +
PARKING AID MODULE (PAM) (RIGHT "C" PILLAR)
REAR ENTERTAINMENT MODULE (RETM) (W/ DVD) (RIGHT SIDE OF DASH)
VIO/ORG WIRE
W/ AMPLIFIER
W/ POWER LIFTGATE
W/O AMPLIFIER
W/O POWER LIFTGATE
W/O POWER LIFTGATE, AMPLIFIER
WHT WIRE
WHT/BLU WIRE
Go to component -> Computer data lines circuit (2 of 2) -> W/O POWER LIFTGATE, AMPLIFIER
