Ford Flex I (2008-2013) up wiper relay Wiring diagram

This page shows the only wiring diagram for the component.up wiper relay, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram up wiper relay (1 of 1)

Wiring diagram up wiper relay for Ford Flex I (2008-2013)

Get access

1) OFF 4) REAR WASH BLK WIRE BLU WIRE ELECTRONICS FRONT WASHER RELAY FRONT WIPER/ WASHER CIRCUIT FUSE 43 GRN WIRE GRY WIRE HOT AT ALL TIMES BATTERY JUNCTION FUSE 15 BOX (BJB) (LEFT SIDE OF ENGINE COMPT) HOT IN RUN OR ACC MULTI- FUNCTION SWITCH REAR WASHER RELAY REAR WIPER MOTOR ASSEMBLY (CENTER OF LIFTGATE) REAR WIPER RELAY REAR WIPER SWITCH RED WIRE SMART JUNCTION BOX (SJB) UP WIPER RELAY VIO WIRE WHT WIRE WINDSHIELD WASHER PUMP MOTOR (WASHER FLUID RESERVOIR) WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) YEL WIRE

Go to component: -> Rear wiper/washer circuit -> UP WIPER RELAY
