Ford Flex I (2008-2013) right rear seat cushion heater Wiring diagram
This page shows the only wiring diagram for the component.right rear seat cushion heater, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear seat cushion heater (1 of 1)
1 2 3 4 5 6 BATT-DRV RUN/START PASS BATT LR HEATER FEED GND RR HEATER FEED
11 12 10 RH LOW LED RH HIGH LED GND
14 15 LH LOW LED LH HIGH LED
18 16 ILLUMINATION LH SYS LO/HI/OFF
AUXILIARY CLIMATE CONTROL ASSEMBLY
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
FUSE 35
FUSE 40
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT CUSHION HEATER
LH SYS LO/HI/OFF(V-) LR SEAT NTC LH LOW LED+ LH HIGH LED+
NCA WIRE
REAR HEATED SEAT MODULE (CENTER CONSOLE)
RETURN
RH SYS LO/HI/OFF
RH SYS LO/HI/OFF(V-) RR SEAT NTC RH LOW LED+ RH HIGH LED+
RIGHT REAR SEAT BACK HEATER
RIGHT REAR SEAT CUSHION HEATER
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRY WIRE
Go to component: -> Rear heated seats circuit -> RIGHT REAR SEAT CUSHION HEATER
