Ford Flex I (2008-2013) rear cupholder lamp Wiring diagram
This page shows the only wiring diagram for the component.rear cupholder lamp, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear cupholder lamp (1 of 1)
AMBIENT LIGHTING MODULE (CENTER CONSOLE)
AMBIENT LIGHTING SWITCH
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
COURTESY
FRONT CUPHOLDER LAMP
FRONT INTERIOR/ MAP LAMP ASSEMBLY
GRN WIRE
GRN/RED WIRE
GRY/VIO WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LED SIG
LEFT FRONT FOOTWELL LAMP
LEFT REAR FOOTWELL LAMP
OFF ON
ORG/ WIRE
REAR CUPHOLDER LAMP
RED WIRE
RIGHT FRONT FOOTWELL LAMP
RIGHT REAR FOOTWELL LAMP
RTN
STORAGE BIN LAMP
THIRD ROW SEAT INTERIOR/ MAP LAMPS ASSEMBLY
VIO/GRY WIRE
VPWR
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> REAR CUPHOLDER LAMP
