Ford Flex I (2008-2013) pawl sw sig latch sw full latch sw half Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 GND CINCH UNCINCH VBATT BLK/BLU WIRE BLK/GRY WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BOX (SJB) (LEFT SIDE OF DASH) BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE CINCH MOTOR CLUTCH HALL EFFECT SENSOR LIFTGATE DRIVE MOTOR ASSEMBLY (LEFT "D" PILLAR) CLUTCH VBATT COMPUTER DATA LINES SYSTEM DRIVE MOTOR ENCODER RTN PINCH SENSOR RTN CHIME MS CAN - MS CAN + LIFTGATE RELEASE ENCODER SIG 1 ENCODER SIG 2 CHIME RTN FRONT POWER LIFTGATE OPEN/CLOSE SWITCH FUSE 14 FUSE 17 GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) FUSE 34 LEFT LIFTGATE OBSTACLE DETECTION STRIP (LEFT SIDE OF LIFTGATE) LIFTGATE LATCH/ UNLATCH ASSEMBLY (LIFTGATE ASSEMBLY) LIFTGATE REL (FET) LIFTGATE RELEASE SWITCH LIFTGATE SW LIFTGATE/TRUNK MODULE (LTM) (LEFT "D" PILLAR) MICRO - MOTOR OPEN 1 MOTOR CLOSE 1 NCA WIRE PAWL SW SIG LATCH SW FULL LATCH SW HALF POWER LIFTGATE CHIME (LEFT "D" PILLAR) REAR INTERIOR SW LT PINCH STRIP SIG SECTOR GEAR CLOSE REAR POWER LIFTGATE OPEN/CLOSE SWITCH RIGHT LIFTGATE OBSTACLE DETECTION STRIP (RIGHT SIDE OF LIFTGATE) SECTOR GEAR OPEN CONSOLE OPEN/ CLOSE SW SMART JUNCTION VIO WIRE VIO/BRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT/BLU WIRE YEL WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE
