Ford Flex I (2008-2013) pats rx Wiring diagram
This page shows the only wiring diagram for the component.pats rx, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pats rx (1 of 1)
BLK/BLU WIRE
BLU WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EXCEPT TURBO TURBO
FUSE 26 (LEFT SIDE OF DASH)
FUSE 36 FUSE 29
GROUND
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
HS CAN+
INSTRUMENT CLUSTER (IC)
LOGIC GND
MS CAN +
PASSIVE ANTI-THEFT TRANSCEIVER (TOP OF STEERING COLUMN)
PATS RX
PATS TX
POWER
RED WIRE
RUN/START
RX OUTPUT
SMART JUNCTION BOX (SJB)
TX OUTPUT
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component: -> Passive anti-theft circuit -> PATS RX
