Ford Flex I (2008-2013) passenger side window control switch Wiring diagram
This page shows the only wiring diagram for the component.passenger side window control switch, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side window control switch (1 of 1)
ACCESSORY DELAY RELAY
AUTO
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CIRCUIT BREAKER
DN UP
DOWN
DRIVER SIDE FRONT POWER WINDOW MOTOR (DRIVER'S DOOR)
FUSE 41
GRN/BLU WIRE
GRN/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT
LEFT REAR
LOCK OUT DN
LOCK OUT PWR
MASTER WINDOW CONTROL SWITCH
MICRO -
NOT USED
PASSENGER SIDE WINDOW CONTROL SWITCH
RED WIRE
RIGHT FRONT
RIGHT REAR
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO WIRE
VIO/WHT WIRE
VPWR
WHT/ORG WIRE
YEL WIRE
YEL/VIO WIRE
Go to component: -> Power windows circuit (1 of 2) -> PASSENGER SIDE WINDOW CONTROL SWITCH
