Ford Flex I (2008-2013) passenger side front seat control switch Wiring diagram

This page shows the only wiring diagram for the component.passenger side front seat control switch, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger side front seat control switch (1 of 1)

Wiring diagram passenger side front seat control switch for Ford Flex I (2008-2013)

Get access

AFT FWD BATTERY BLK WIRE BLU WIRE DOWN FRONT HEIGHT FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HORIZONTAL HOT AT ALL TIMES PASSENGER SEAT FRONT HEIGHT MOTOR (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT REAR HEIGHT MOTOR (UNDER FRONT PASSENGER'S SEAT) PASSENGER SIDE FRONT SEAT CONTROL SWITCH REAR HEIGHT RED WIRE VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Power seats circuit, 6-way passenger seat -> PASSENGER SIDE FRONT SEAT CONTROL SWITCH
