Ford Flex I (2008-2013) left front footwell lamp Wiring diagram

This page shows the only wiring diagram for the component.left front footwell lamp, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left front footwell lamp (1 of 1)

Wiring diagram left front footwell lamp for Ford Flex I (2008-2013)

Get access

AMBIENT LIGHTING MODULE (CENTER CONSOLE) AMBIENT LIGHTING SWITCH BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE BRN/YEL WIRE COURTESY FRONT CUPHOLDER LAMP FRONT INTERIOR/ MAP LAMP ASSEMBLY GRN WIRE GRN/RED WIRE GRY/VIO WIRE INSTRUMENT ILLUMINATION CIRCUIT LED SIG LEFT FRONT FOOTWELL LAMP LEFT REAR FOOTWELL LAMP OFF ON ORG/ WIRE REAR CUPHOLDER LAMP RED WIRE RIGHT FRONT FOOTWELL LAMP RIGHT REAR FOOTWELL LAMP RTN STORAGE BIN LAMP THIRD ROW SEAT INTERIOR/ MAP LAMPS ASSEMBLY VIO/GRY WIRE VPWR YEL/GRN WIRE

Go to component: -> Courtesy lamps circuit (2 of 2) -> LEFT FRONT FOOTWELL LAMP
