Ford Flex I (2008-2013) kapwr feps sccs sccs rtn c sigrtn Wiring diagram
This page shows the only wiring diagram for the component.kapwr feps sccs sccs rtn c sigrtn, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram kapwr feps sccs sccs rtn c sigrtn (1 of 1)
A/C PRESSURE TRANSDUCER (RIGHT FRONT OF ENGINE COMPT)
ACCR
ACPT
AIR CONDITIONING SYSTEM
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BOO BPS FC-V
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
C REF
C-SIGRTN
CANV FPC
CASE GND
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM CRUISE
CONTROL SYSTEM
COOLING FANS SYSTEM
EVAP CANISTER VENT CONTROL SOLENOID (UNDER RIGHT REAR OF VEHICLE)
EVMV
FTPREF FPM
FUSE 23
GENCOM GENMON
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) FUSE 14
HS CAN + HS CAN -
IAT
INJPWRM SMC SMRC
ISP-R PCM RLY CTRL
KAPWR FEPS SCCS SCCS RTN C SIGRTN
MAF
MAF MAFRTN IAT FTP
MAFRTN
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR (LEFT REAR OF ENGINE)
OVERDRIVE CANCEL
POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT)
PWR GND
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.5l (1 of 6) -> KAPWR FEPS SCCS SCCS RTN C SIGRTN
