Ford Flex I (2008-2013) fuse 26 fuse 15 fuse 35 Wiring diagram
This page shows the only wiring diagram for the component.fuse 26 fuse 15 fuse 35, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 26 fuse 15 fuse 35 (1 of 1)
A/C FUEL PUMP CLUTCH RELAY RELAY
AUDIO CONTROL MODULE (ACM)
AUXILIARY BLOWER MOTOR RELAY
BATTERY JUNCTION BOX (BJB)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLOWER MOTOR RELAY
BLU/GRY WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/ WHT WIRE
DIODE
ENGINE COOLING FAN MOTOR
EVAP CANISTER VENT CONTROL SOLENOID
EXCEPT TURBO
FLOOR SHIFTER
FROM FUSE 27 (DIAGRAM 4 OF 4)
FROM FUSE 7 (DIAGRAM 1 OF 4)
FROM PCM POWER RELAY (DIAGRAM 2 OF 4)
FUSE
FUSE 10
FUSE 11 FUSE 20
FUSE 25
FUSE 26 FUSE 15 FUSE 35
FUSE 27 FUSE 24
FUSE 28
FUSE 31
FUSE 33
FUSE 4
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/VIO WIRE
IGNITION LOCK SOLENOID
IGNITION SWITCH
KEY-IN IGNITION SWITCH
MICRO -
OFF
ONE TOUCH INTEGRATED
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
REAR REAR WIPER MOTOR WINDOW ASSEMBLY DEFROST RELAY
REAR WINDOW DEFROST RELAY
RED WIRE
RED/ WHT WIRE
REVERSING REAR BLOWER LAMPS WIPER MOTOR RELAY RELAY RELAY
RUN WIRE
SMART JUNCTION BOX (SJB)
SMRC
STARTER RELAY
THIRD ROW POWER SEAT RELAY
TO CONSOLE REFRIGERATION RELAY (DIAGRAM 4 OF 4)
TO EVAP CANISTER VENT CONTROL SOLENOID (DIAGRAM 2 OF 4)
TURBO
USED)
VIO/GRN WIRE
VIO/RED WIRE
WHT RED/ WIRE
WHT/ORG WIRE
WHT/RED WIRE
WINDSHIELD WIPER MOTOR
WIPER RUN/PARK RELAY
YEL WIRE
YEL/RED WIRE
