Ford Flex I (2008-2013) fuel gauge sensor Wiring diagram
This page shows the only wiring diagram for the component.fuel gauge sensor, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel gauge sensor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRAKE PEDAL POSITION (BPP) SWITCH (LEFT SIDE OF DASH)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
ENS
FP PWR
FP RTN
FPC
FPM
FUEL GAUGE SENSOR
FUEL PUMP
FUEL PUMP MODULE (IN FUEL TANK)
FUEL RTN
FUEL TANK PRESSURE (FTP) SENSOR (FUEL TANK ASSEMBLY)
FUEL TANK UNIT
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HS CAN+
INPUT 1
INSTRUMENT CLUSTER (IC)
PNK WIRE
RESTRAINTS CONTROL MODULE (RCM) (CENTER CONSOLE)
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component: -> Wiring diagram engine performance 3.5l (2 of 6) -> FUEL GAUGE SENSOR
