Ford Flex I (2008-2013) exterior lights system 14 2 turbo except turbo Wiring diagram

This page shows the only wiring diagram for the component.exterior lights system 14 2 turbo except turbo, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram exterior lights system 14 2 turbo except turbo (1 of 1)

Wiring diagram exterior lights system 14 2 turbo except turbo for Ford Flex I (2008-2013)

Get access

AUTO- DIMMING INTERIOR MIRROR UNIT BATTERY JUNCTION BLK WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE COMPASS ENGINE CONTROLS SYSTEM EXTERIOR LIGHTS SYSTEM 14 2 TURBO EXCEPT TURBO FUSE FUSE BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GRN/BRN WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED INSTRUMENT CLUSTER (IC) REVERSE REVERSING LAMPS RELAY RLC TURBO EXCEPT TURBO VPWR WHT/BLU WIRE YEL/RED WIRE

Go to component: -> Electrochromic mirror circuit -> EXTERIOR LIGHTS SYSTEM 14 2 TURBO EXCEPT TURBO
