Ford Flex I (2008-2013) encoder rtn pinch sensor rtn chime ms can - ms can + liftgate release wiring diagram
This page shows the only wiring diagram for the component.encoder rtn pinch sensor rtn chime ms can - ms can + liftgate release, which is found in the car Ford Flex I (2008-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
encoder rtn pinch sensor rtn chime ms can - ms can + liftgate release wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 GND CINCH UNCINCH VBATT
BLK/BLU WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BOX (SJB) (LEFT SIDE OF DASH)
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
CINCH MOTOR
CLUTCH HALL EFFECT SENSOR LIFTGATE DRIVE MOTOR ASSEMBLY (LEFT "D" PILLAR)
CLUTCH VBATT
COMPUTER DATA LINES SYSTEM
DRIVE MOTOR
ENCODER RTN PINCH SENSOR RTN CHIME MS CAN - MS CAN + LIFTGATE RELEASE
ENCODER SIG 1 ENCODER SIG 2 CHIME RTN
FRONT POWER LIFTGATE OPEN/CLOSE SWITCH
FUSE 14
FUSE 17
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) FUSE 34
LEFT LIFTGATE OBSTACLE DETECTION STRIP (LEFT SIDE OF LIFTGATE)
LIFTGATE LATCH/ UNLATCH ASSEMBLY (LIFTGATE ASSEMBLY)
LIFTGATE REL (FET)
LIFTGATE RELEASE SWITCH
LIFTGATE SW
LIFTGATE/TRUNK MODULE (LTM) (LEFT "D" PILLAR)
MICRO -
MOTOR OPEN 1 MOTOR CLOSE 1
NCA WIRE
PAWL SW SIG LATCH SW FULL LATCH SW HALF
POWER LIFTGATE CHIME (LEFT "D" PILLAR)
REAR INTERIOR SW LT PINCH STRIP SIG SECTOR GEAR CLOSE
REAR POWER LIFTGATE OPEN/CLOSE SWITCH
RIGHT LIFTGATE OBSTACLE DETECTION STRIP (RIGHT SIDE OF LIFTGATE)
SECTOR GEAR OPEN CONSOLE OPEN/ CLOSE SW
SMART JUNCTION
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power liftgate circuit -> ENCODER RTN PINCH SENSOR RTN CHIME MS CAN - MS CAN + LIFTGATE RELEASE
